Wire diameter: O5-O12 coil and cold rolling ribbed wire; O5-O12 hot rolled rebar
Cutting length: 6m (also can be defined by customer)
Speed: 130 m/min (High speed);100m/min (Medium speed); 75 m/min (Low speed)
Tolerance of cut-to-length: <= ±1 mm
Linearity of straightening: <= ±2 mm/m
Power
Cutting motor 4 Kw
Straightening motor 22 Kw
Main machine dimension: 3040×1125×1310 mm |
